Description

In the past, the 360 Series Label Applicator set the industry standard for providing quality applications for your needs. With the second generation 360a Label Applicator by CTM Labeling Systems, the industry standard evolved. In 2023, CTM improves upon the 360a introducing the 360a Model Y. This incredibly versatile and extremely durable applicator provides the essentials while also improving work processes while offering a state-of-the-art electronics and communications package.

Key Features

  • Configurable to different applicator types: merge, blow-on or tamp
  • Adjustable widths to allow for multiple label sizes
  • Capable of dispensing labels at up to 1,500 inches per minute (up to 3,000 inches per minute when combined with a secondary unwind and vacuum takeaway)
  • Self-teaching label sensor

Built For Many Label Applications

The 360a Model Y Label Applicator is extremely versatile. The label applicator can be configured in multiple ways to allow for various label applications. Regardless of the surface or size, the 360a Model Y is capable.

Each 360a Model Y Label Applicator is configurable to one of three application methods: air blow, tamp-blow and merge. Determining which one you use will depend on the product surface, location of the label and label materials you plan on using. Each applicator is available in widths of 5, 7.5, or 10 inches to allow for a variety of label sizes.

State-Of-The-Art Technology

The 360a Model Y Label Applicator comes equipped with industry-leading technology that is designed to help improve workloads. Each applicator is built with a servo motor and drive package. Matched with a planetary gearbox, the applicator can perform consistently and accurately

Other new features of the 360a Model Y include Safe Torque Off (STO) functionality (IEC 61508 SIL3 safety certification) as well as Ethernet/IP for system controls integrations.

The 360a Model Y controller is also equipped with Printed Circuit Board (PCB) connectivity with external connectors to accommodate the following: low label – single, double, or triple alarm stack – web break – encoder velocity compensation – loose loop control – product shape profiling imprinting – zero downtime configuration – two channel E-Stop monitoring. Each machine is shipped preprogrammed and can have the additional hardware installed later for simple “plug n play” operations. The electronic control assembly is packaged as a module and can be easily removed for repair or replacement, eliminating costly downtime and servicing. Software updates can be downloaded from a remote source or emailed for user friendly support.

Ease-Of-Use

CTM’s 360a Model Y Label Applicator comes with a 7-inch, 256 color, TFT touch screen operator. This operator is vital to the applicator, and it provides a self-diagnostic platform and a multi-level set-up. The bright and bold high-contrast display is sure to be visible regardless of the lighting conditions.

Each applicator can be converted to a left-handed or right-handed with little to no change in parts. It makes them the perfect companion no matter where in your facility the 360a Model Y Label Applicator is placed.

Utilizing state-of-the-art technology and industry-leading expertise, the 360a Model Y Label Applicator is the right applicator for many businesses. CTM Labeling Systems prides itself in providing industry-leading labeling systems and customer support. Contact us today to get started.

Man working on machines.Secrets for Success Cover.

Download Our Free
Whitepaper

CTM Labeling Systems is a major supplier of automated
labeling equipment for Amazon’s 100+fulfillment centers.
See how the relationship started and how it has impacted
both companies.

Learn About The Partnership

Machine wiring background.CTA - Image for machine teardown.

Machine Breakdown: The 360a
Series Applicator Model Y

Watch the machine breakdown of the all-new 360a Series Model Y Applicator
to learn about technology updates and see how it can benefit you!

Watch Now!

THC CTA background.CTA - Cannabis Labeling content offer.

State-by-State THC Cannabis
Labeling Regulations

With the evolving laws surrounding medical and recreational marijuana use, it’s
important to stay up-to-date with label requirements. Find out what your state
requires with our FREE guide!

Get the Guide!

5 Strategies CTA background.5 strategies to slash lead times content offer image.

Slash Lead Times STAT

Everyone wants their business to be booming — but, do you have
the capacity to keep up with demand? Get our FREE guide with
multiple strategies to slash lead times and keep customers happy!

Start Slashing Lead Times

FAQ content offer background.FAQ content offer CTA.

FAQs for Beer & Alcohol
Labeling Requirements

Download Now!

Product Comparison CTA background.Product Comparison guide image for CTA.

Find The Right Labeler
For Your Business Needs!

View our Product Comparison Guide to learn more about our
Commercial, Print & Apply, and Custom-Designed Label Applicators!

Compare Labelers!

Designing Label background image.Designing Labeler Content Offer CTA image.

Designing Your Custom
Labeler From Start to Finish!

Learn more about designing a custom labeler for your product’s shape,
label size, application method, and speed of your conveyor!

Get the Guide!

Organic Labeling Your Products background for CTA.Designing Labeler Content Offer CTA image.

Explained: Organic
Label Requirements

View our guide on organic product labeling to learn more about following
organic labeling requirements and ensure your customers know exactly
what they are buying!

Meet Requirements!

Label Requirements Background image.Label requirements CTA image.

Everything You Need to Know
About Product Label Requirements

Did you know there are often requirements that must be included on your label?
Learn about label requirements across a variety of labels and products!

Meet Requirements!

Man working on machines background image.FAQ content offer CTA image.

Quick Answers to All
Your Labeling Questions

Whether you’re a seasoned professional or a startup, knowing
which machine is right for you can be difficult. Don’t let the unknown
stop you from finding the right labeling solution for your business.

Get the Guide!

Exclusive Demo Background Image.Video image for CTA.

Exclusive Demo: 3600a-PA
Labeler in Action

Explore CTM’s 3600a-PA, a precise labeler designed for multiple
application points with customizable features and an intuitive interface.
Supported by experts, it’s the perfect solution for your labeling needs.

Watch Demo

Exclusive Demo Background Image.CTM Annin Case Study

Custom Solution for
RFID Labeling Challenge

Annin Flagmakers revolutionized their
RFID labeling process with a custom solution from
CTM Labeling Systems. See how!

Watch Video

Specifications

Series

360a

Voltage

120 VAC
240 VAC Available

Current

5 amps

Frequency

50/60 Hz

Phase

Single

AirConsumption @ 60-90 psi

Up to 4 CFM

Label Placement

± 1/32 in

Air Blow Width

28 in

Air Blow Height

24 in

Air Blow Depth

27 1/2 in

Merge Width

29 in

Merge Height

25 in

Merge Depth

27 1/2 in

Tamp Width

28 in

Tamp Height

22 1/2 in

Tamp Depth

27 1/2 in

Product Sensing

Retroreflective scanner provided as standard, other types available

Label Sizes

Min. Air Blow (W X L)

3/4 X 3/4 in

Min. Merge (W X L)

3/4 X 3/4 in

Min. Tamp (W X L)

3/4 X 3/4 in

Max. Air Blow (W X L)

7.5 X 9 in

Max. Merge (W X L)

10 X 20 in

Max. Tamp (W X L)

10 X 10 in

Label Roll Size

Max. OD Core

12 in

Max. ID Core

3 in

Optional

16″ OD or 20″ OD x 3″ or 6″ ID cores

CTM has built a reputation based on decades of good design, local manufacturing, and excellent support for customers interested in purchasing automated labeling systems.
